Core Data Concepts: Formats, Storage, and Processing

radio_button_uncheckedshort_text1. Why data fundamentals matter

Systems, applications, sensors, and connected devices produce more data every year. Collection and storage are less expensive than in the past, so organizations of every size can use information to improve products, operations, revenue, and risk decisions. The value does not come from accumulation alone: data must be represented, stored, processed, and interpreted appropriately.

A sound architecture starts by asking what the data describes, how quickly it changes, who consumes it, and whether the workload records live events or studies history. These questions determine whether a file, database, transactional engine, or analytical platform is the better fit.

Topic summary

Data becomes useful when an organization can capture it, keep it reliably, and analyze it in a form suited to the business question.

radio_button_uncheckedshort_text2. Entities, attributes, and the four broad data forms

Data records facts, descriptions, measurements, and observations. Business data commonly represents entities such as customers, products, orders, or devices. An entity instance has attributes: a customer may have a name, postal address, telephone numbers, and contact preferences.

Topic summary

Identify the entity and its attributes first, then determine whether the representation is fixed, flexible, free-form, or an embedding.

radio_button_uncheckedshort_text3. Structured data and fixed schemas

Structured data conforms to a predefined schema. A tabular representation uses rows for entity instances and columns for attributes. Because each row exposes the same fields and compatible data types, applications can validate, sort, join, aggregate, and query the data predictably.

Structured data is frequently stored in relational databases, where tables reference one another through key values. A fixed schema improves consistency, but schema changes must be managed because producers and consumers rely on the agreed shape.

Topic summary

Structured data trades flexibility for consistency and predictable querying.

radio_button_uncheckedshort_text4. Semi-structured data and JSON

Semi-structured data retains organization without requiring every instance to contain identical fields. One customer can have two telephone numbers, another only an email address, and a third an apartment number. The document still follows recognizable names and nesting, but optional and repeated elements are allowed.

{
  "customerId": 101,
  "name": "Asha",
  "contacts": [
    { "type": "email", "value": "asha@example.com" },
    { "type": "phone", "value": "+1-555-0101" }
  ]
}

JavaScript Object Notation (JSON) is a widespread representation for this model. Objects use braces, collections use brackets, and attributes appear as name-value pairs. JSON can also represent fully structured data; its key characteristic is the ability to express hierarchy and variation.

Topic summary

Semi-structured representations preserve machine-readable organization while allowing records to differ.

radio_button_uncheckedshort_text5. Unstructured data, BLOBs, and vector embeddings

Documents, images, audio, video, and application-specific binary files do not necessarily expose a shared schema that a database engine can interpret directly. They are often stored as Binary Large Objects (BLOBs) and rendered or decoded by an application.

AI solutions increasingly create embeddings: arrays of numbers that capture semantic characteristics of text, images, or other content. A vector database can compare these embeddings by similarity, enabling an assistant to retrieve relevant document passages before answering a natural-language question. The original file remains unstructured even though its embedding is a structured numeric representation.

Topic summary

BLOB storage keeps raw content; vector storage keeps embeddings that make semantic retrieval efficient.

radio_button_uncheckedshort_text6. Choosing between file stores and databases

File stores organize and retrieve complete files. Databases manage records and expose query, indexing, integrity, and concurrency capabilities. The boundary is not absolute - a file system is technically a form of data store, and modern lakehouses add database-like table semantics over files - but the distinction is useful for architecture decisions.

Topic summary

Select storage from access patterns, integrity requirements, scale, latency, and data form - not from file extension alone.

radio_button_uncheckedshort_text7. File storage from local disks to the cloud

Files can live on personal disks, removable media, shared network systems, or cloud storage. Organizations increasingly centralize important files in cloud services to gain elastic capacity, durability, security controls, and cost-effective storage for large volumes.

Format selection depends on who reads and writes the data, whether people need to inspect it, and whether compact storage and fast processing are more important than readability. A format suited to data exchange might be inefficient for analytics, while a columnar format might be awkward for a streaming producer.

Topic summary

Centralized cloud file storage improves scale and reliability, while format choice determines interoperability and processing efficiency.

radio_button_uncheckedshort_text8. Delimited and fixed-width text

Delimited text separates fields and rows with agreed characters. Comma-separated values (CSV) commonly uses commas between fields and line breaks between records; a header row can name the columns. Tab-separated values (TSV), space-delimited data, and fixed-width records are alternatives.

FirstName,LastName,Email
Asha,Patel,asha@example.com
Diego,Ruiz,diego@example.com

These formats are portable and readable, but escaping delimiters, character encoding, null values, dates, and data types require explicit conventions. Fixed-width files avoid delimiter ambiguity but waste space and are less adaptable to schema changes.

Topic summary

Delimited text is excellent for broad interchange, provided producers and consumers agree on encoding, delimiters, headers, and data types.

radio_button_uncheckedshort_text9. JSON, XML, and binary files

JSON expresses nested objects and collections with relatively little syntax, making it common for APIs, configuration, and event messages. Extensible Markup Language (XML) uses elements and attributes enclosed by tags. XML is more verbose but remains important in established enterprise systems and standards.

<customers>
  <customer id="101">
    <name>Asha Patel</name>
    <email>asha@example.com</email>
  </customer>
</customers>

Text formats map bytes to characters through encodings such as Unicode. Binary formats store bytes that an application must interpret, such as a JPEG image, audio stream, video, archive, or proprietary document. Data professionals often call these binary files BLOBs.

Topic summary

JSON and XML describe hierarchical data; binary formats prioritize application-specific representation rather than human readability.

radio_button_uncheckedshort_text10. Parquet: columnar analytics storage

Apache Parquet is a columnar format and a de facto standard for modern lakehouses. A file is divided into row groups, and values from each column are stored together within a group. Metadata describes the chunks, allowing an engine to skip irrelevant data and read only the requested columns.

Columnar layout enables efficient compression and encoding, particularly when adjacent values share characteristics. Parquet also handles nested data. It is optimized for analytical scans, not for people to read in a text editor or for frequent single-record updates.

Topic summary

Parquet reduces analytical I/O by organizing and compressing data by column.

radio_button_uncheckedshort_text11. Avro and Delta Lake

Apache Avro is row-based. Each file contains a header that describes the schema in JSON and binary blocks containing the records. Keeping each record together makes Avro useful for data exchange, streaming, compact serialization, and minimizing network bandwidth.

Delta Lake is an open-source table format built on Parquet. A transaction log records table changes and adds ACID transactions, reliable updates, schema management, versioning, and time travel over files in a data lake. Parquet provides the data files; the Delta log provides table history and transactional coordination.

Topic summary

Avro favors row-oriented exchange; Delta Lake turns Parquet files into reliable, versioned lakehouse tables.

radio_button_uncheckedshort_text12. What a database adds

In professional data work, a database is a dedicated system for storing, managing, and querying records. Beyond persistence, it can provide indexes, constraints, concurrency control, security, backup, recovery, and query optimization. These capabilities distinguish a database management system from a directory of files.

Topic summary

A database manages records and their behavior, not only the bytes that store them.

radio_button_uncheckedshort_text13. Relational databases, keys, normalization, and SQL

A relational database stores structured entities in tables. A primary key uniquely identifies each row, and a foreign key references a row in another table. These relationships let an order identify its customer without repeating the full customer record.

Normalization separates related entities to reduce duplication and update anomalies. It improves transactional consistency, although analytical schemas may deliberately denormalize data to accelerate queries. Structured Query Language (SQL) is based on ANSI standards, so its core ideas are similar across database products even when implementations add extensions.

Topic summary

Relational databases use tables, keys, constraints, normalization, and SQL to preserve structured relationships.

radio_button_uncheckedshort_text14. Four common nonrelational models

Nonrelational databases do not require a relational schema and are often grouped under the term NoSQL, even though some offer SQL-like query languages. They are selected for flexible schemas, distribution, specialized relationships, or very high scale.

Topic summary

NoSQL is a family of models; match key-value, document, column-family, or graph storage to the dominant query pattern.

radio_button_uncheckedshort_text15. Transactional processing, OLTP, and CRUD

A transaction is a small, discrete business event, such as paying for an order or transferring money. Online Transaction Processing (OLTP) systems support live line-of-business applications and can handle millions of events while keeping data available with low latency.

OLTP databases are optimized for both reads and writes. Applications create, retrieve, update, and delete records - the CRUD operations - while the database protects integrity under concurrent activity. Schemas are often normalized so each transaction touches a small number of precise records.

Topic summary

OLTP records current business events through fast, reliable reads and writes.

radio_button_uncheckedshort_text16. ACID transaction guarantees

Consider transferring $40 from Account A, initially $100, to Account B, initially $50. The correct result is $60 and $90, and no observer should see a permanently partial transfer.

Topic summary

ACID makes a transaction indivisible, valid, isolated from interference, and permanent after commit.

radio_button_uncheckedshort_text17. Analytical processing, ETL, and ELT

Analytical systems are read-mostly and hold historical data or business metrics. They may analyze a single snapshot or a time series of snapshots. Operational data is commonly extracted, transformed, and loaded (ETL), or extracted and loaded before transformations are applied (ELT), a pattern common in modern lakehouses.

1. Ingest operational files, events, and database records.
2. Clean, standardize, join, and enrich the data before or after loading.
3. Organize data into lakehouse or warehouse tables.
4. Build aggregations and semantic definitions.
5. Deliver reports, visualizations, dashboards, data science, and AI workloads.

Topic summary

ETL transforms before loading; ELT loads first and uses the destination platform for transformation.

radio_button_uncheckedshort_text18. Data lake, warehouse, and lakehouse

Analytical schemas often denormalize data from OLTP sources. Some duplication can reduce joins and improve read performance. This is a deliberate trade-off: transactional models optimize updates and integrity, while analytical models optimize broad scans, aggregations, and reporting.

Topic summary

Lakes prioritize flexible files, warehouses prioritize relational analytics, and lakehouses combine both approaches.

radio_button_uncheckedshort_text19. OLAP, semantic models, facts, dimensions, and users

An Online Analytical Processing (OLAP) model - now commonly called a semantic model and historically called a cube - stores or defines aggregations for fast analysis. Numeric measures from fact tables are evaluated across dimension tables such as date, customer, product, and geography. Hierarchies allow drill-down from region to city to address and drill-up in the opposite direction.

Power BI semantic models are a common example. Data scientists may explore files directly in a lake, data analysts may query warehouse tables and build visualizations, and business users typically consume curated metrics through reports and dashboards.

Topic summary

Semantic models translate stored data into consistent measures, dimensions, hierarchies, and business-ready analysis.

radio_button_uncheckedshort_text20. Modern platforms and the medallion architecture

Microsoft Fabric is a unified SaaS analytics platform that brings storage, data engineering, warehousing, data science, real-time capabilities, and reporting into a shared environment. Azure Databricks supports large-scale data engineering and data science and uses Delta Lake as a standard table format. Microsoft Purview supplies unified data security, governance, and compliance across sources. Power BI provides semantic modeling, visualization, and business intelligence experiences.

A medallion architecture creates explicit quality boundaries. Bronze retains raw source records for traceability and reprocessing. Silver contains cleansed and conformed data with duplicates removed and types standardized. Gold contains aggregated, business-ready models for reports and analytics. Microsoft Fabric and Azure Databricks also provide Copilot experiences for natural-language exploration.

Topic summary

Fabric and Databricks process analytics, Purview governs data, Power BI serves business insight, and medallion layers make quality progression explicit.

radio_button_uncheckedshort_text21. Integrated retail scenario

A retailer records orders and inventory changes in a normalized relational OLTP database. Product images are kept in blob storage, flexible catalog attributes in JSON documents, and application events in Avro. The analytical platform ingests these sources into Bronze, standardizes customers and products in Silver, and publishes sales and inventory measures in Gold.

Parquet and Delta Lake support efficient lakehouse tables. A semantic model defines revenue, margin, units, dates, stores, and products for Power BI. Data scientists can use lakehouse files for forecasting, while business users view dashboards. Microsoft Purview helps discover, classify, protect, and govern the participating sources.

Topic summary

Real solutions combine storage models: OLTP for current events, object storage for files, document data for flexibility, and a governed analytical platform for trends.

radio_button_uncheckedshort_text22. Module assessment with explanations

1. Natural-language retrieval over documents: choose a vector database because it searches embeddings by semantic similarity.
2. Large images and videos: choose blob storage rather than a relational or column-family database.
3. High-volume transactional reads and writes: choose a relational OLTP database when relationships and ACID integrity are central.
4. Parquet advantage: columnar storage enables efficient compression, encoding, and selective reads.
5. Retail workflow: use OLTP for live transactions and OLAP or a semantic model for trend analysis.
6. Key-value distinction: every record is retrieved by a unique key associated with an arbitrary value.
7. Inventory and customer transactions: choose OLTP, not a file system or OLAP engine.
8. Slow business-intelligence queries: optimize the analytical or OLAP layer rather than the transactional system.
9. Unique Parquet trait among the listed formats: columnar storage.

Topic summary

Assessment questions test whether you can match data form, store, database model, and processing workload to a concrete requirement.

radio_button_uncheckedshort_text23. Final review and memory map

• Representation: structured, semi-structured, unstructured, and vector.
• Files: delimited text, JSON, XML, BLOB, Parquet, Avro, and Delta Lake.
• Databases: relational plus key-value, document, column-family, graph, and vector models.
• Transactions: OLTP, CRUD, and ACID.
• Analytics: ETL or ELT into lake, warehouse, or lakehouse; semantic models accelerate consumption.
• Platforms: Microsoft Fabric, Azure Databricks, Microsoft Purview, and Power BI; Bronze, Silver, and Gold organize data quality.

Topic summary

For DP-900, always connect the requirement to four decisions: representation, storage, processing pattern, and consumer.

radio_button_uncheckedshort_text24. Official references

• Microsoft Learn - Describe core data concepts.
• Microsoft Learn - Microsoft Fabric documentation.
• Microsoft Learn - Azure Databricks documentation.
• Microsoft Learn - Microsoft Purview documentation.
• Microsoft Learn - Power BI documentation.

Topic summary

Use official documentation to confirm current service capabilities after mastering the durable concepts in this chapter.
